Terex Manlift Specifications
Terex is a Westport, Connecticut company that specializes in producing in manufacturing construction equipment. machinery such as manlifts, boom lifts and aerial lifts. These machinery are designed to facilitate access to places that are hard to reach, buildings and roofs, large equipment, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration refers to a power-driven endless belt. This belt only moves in one direction and contains steps or handholds or paltforms that are attached to the unit to be able to move workers from each floor.
TB85
The TB85 by Terex provides a maximum working height of 91 feet. Additionally, the platform's maximum height reaches 85 feet. This model's maximum width is 8 feet, 1 and 1/2 inches. The TB85 has dimensions which measure 9 feet, 1-inch high and 9 inches wide by 36 feet. This particular model provides a reach of seventy feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal reaching 75 degrees.
Terex TB100
The Terex TB100's maximum working height is 106 feet and the platform's maximum height is 100 feet. When the TB100 is stowed it is 9 feet high by 8 feet, 1 1/2 inches wide by 8 feet. The unit's maximum width is 8 feet, 1 1/2 inches. The boom angle above horizontal is 75 degrees and below horizontal is 14 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The TB110 has a maximum platform height of 100 feet and the unit's overall maximum working height reaches 116 feet. When stowed, this model is 8 feet wide x 9 feet, 4 inches high. The TB110 offers a maximum width of 8 feet and a horizontal reach of 67 feet. This particular model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
